| Number of Circuit |
12/24/30/48/60 (~Max 300) circuit But, it may have smaller or no tru bore depends on number of channels
|
| Operating Speed |
Max 200 rpm ※ High speed slipring available |
| Vibration |
Non-vibrating ※ Vibrating slipring developable |
| Lead Lengths |
STATOR 500mm / ROTOR 500mm ※ Customized length available |
| Voltage |
MAX 210 V/DC, 440 V/AC ※Need an inquiry for using over 300V |
| Current Rating |
Signal Max 5A /circuit
Power Max 80A / circuit |
| Contact Material |
Silver Alloy Type |
| Plated Type |
Ring / Wire Silver Plating
|
| Lead Size Type |
Electric Wire - Teflon insulated ※ AWG standard |
| Noise |
100 milliohm Max.Tested 6 VDC, 50 milliamps when running @ 5 rpm |
| Communication Type |
Sensor, RS communication,CClink, Divice Net (Ethernet, Encoder,USB Please inquire separately) |
