Miniature Slipring
Total
7
Article(s)
1
Page(s)
7
Compact Type SKS-C006
dwg
Item
Specification
Number of Circuit
6 circuit
Operating Speed
Max 250 rpm
Lead Lengths
STATOR 500mm / ROTOR 500mm
Voltage
MAX 210 V/DC, 240 V/AC
Current Rating
MAX 2A / 6 circuit (28AWG)
Plated Type
Gold Alloy Type
Contact Material
Ring / Wire - Gold
Lead Size/Type
Electric Wire - Teflon insulated
※ AWG standard
Noise
60 milliohm Max.Tested 6 VDC, 50 milliamps when running @ 5 rpm
Communication type
Sensor, Ethernet, RS통신, USB(ver 1.1/2.0 MAX 20MB/S)
※ Encoder, CClink, DIVICE NET 문의
6
Compact Type SKS-C012
dwg
Item
Specification
Number of Circuit
12 circuit
Operating Speed
Max 250 rpm
Lead Lengths
STATOR 500mm / ROTOR 500mm
Voltage
MAX 210 V/DC, 240 V/AC
Current Rating
MAX 2A / 6 circuit (28AWG)
Plated Type
Silver Alloy Type
Contact Material
Ring Silver Plating / Wire Silver Alloy
Lead Size/Type
Electric Wire - Teflon insulated
※ AWG standard
Noise
60 milliohm Max.Tested 6 VDC, 50 milliamps when running @ 5 rpm
Communication type
Sensor, Ethernet, RS통신, USB(ver 1.1/2.0 MAX 20MB/S)
※ Encoder, CClink, DIVICE NET 문의
5
Compact Type SKS-C024
dwg
Item
Specification
Number of Circuit
24 circuit
Operating Speed
Max 250 rpm
Lead Lengths
STATOR 500mm / ROTOR 500mm
Voltage
MAX 210 V/DC, 240 V/AC
Current Rating
MAX 2A / 6 circuit (28AWG)
Plated Type
Silver Alloy Type
Contact Material
Ring Silver Plating / Wire Silver Alloy
Lead Size/Type
Electric Wire - Teflon insulated
※ AWG standard
Noise
60 milliohm Max.Tested 6 VDC, 50 milliamps when running @ 5 rpm
Communication type
Sensor, Ethernet, RS통신, USB(ver 1.1/2.0 MAX 20MB/S)
※ Encoder, CClink, DIVICE NET 문의
4
Compact Type SKS-C036
dwg
Item
Specification
Number of Circuit
36 circuit
Operating Speed
Max 250 rpm
Lead Lengths
STATOR 500mm / ROTOR 500mm
Voltage
MAX 210 V/DC, 240 V/AC
Current Rating
MAX 2A / 6 circuit (28AWG)
Plated Type
Silver Alloy Type
Contact Material
Ring Silver Plating / Wire Silver Alloy
Lead Size/Type
Electric Wire - Teflon insulated
※ AWG standard
Noise
60 milliohm Max.Tested 6 VDC, 50 milliamps when running @ 5 rpm
Communication type
Sensor, Ethernet, RS통신, USB(ver 1.1/2.0 MAX 20MB/S)
※ Encoder, CClink, DIVICE NET 문의
3
Mini Type SKS-M005
dwg
pdf
Item
Specification
Number of Circuit
5 circuit
Operating Speed
Max 100 rpm
Lead Lengths
STATOR 100mm / ROTOR 100mm
Voltage
MAX 120 V/DC
Current Rating
MAX 2A / 6 circuit (28AWG)
Plated Type
Gold Alloy Type
Contact Material
Ring / Wire - Gold
Lead Size/Type
Electric Wire - Teflon insulated
※ AWG standard
Noise
60 milliohm Max.Tested 6 VDC, 50 milliamps when running @ 5 rpm
Communication type
Sensor, Ethernet, RS통신, USB(ver 1.1/2.0 MAX 20MB/S)
※ Encoder, CClink, DIVICE NET 문의
2
Mini Type SKS-M006
dwg
pdf
Item
Specification
Number of Circuit
6 circuit
Operating Speed
Max 100 rpm
Lead Lengths
STATOR 500mm / ROTOR 500mm
Voltage
MAX 120 V/DC
Current Rating
MAX 2A / 6 circuit (28AWG)
Plated Type
Gold Alloy Type
Contact Material
Ring / Wire - Gold
Lead Size/Type
Electric Wire - Teflon insulated
※ AWG standard
Noise
60 milliohm Max.Tested 6 VDC, 50 milliamps when running @ 5 rpm
Communication type
Sensor, Ethernet, RS통신, USB(ver 1.1/2.0 MAX 20MB/S)
※ Encoder, CClink, DIVICE NET 문의
1
Mini Type SKS-M012
dwg
Item
Specification
Number of Circuit
12 circuit
Operating Speed
Max 100 rpm
Lead Lengths
STATOR 500mm / ROTOR 500mm
Voltage
MAX 120 V/DC
Current Rating
MAX 2A / 6 circuit (28AWG)
Plated Type
Gold Alloy Type
Contact Material
Ring / Wire - Gold
Lead Size/Type
Electric Wire - Teflon insulated
※ AWG standard
Noise
60 milliohm Max.Tested 6 VDC, 50 milliamps when running @ 5 rpm
Communication type
Sensor, Ethernet, RS통신, USB(ver 1.1/2.0 MAX 20MB/S)
※ Encoder, CClink, DIVICE NET 문의
