Technological Innovation of Slip Ring

Dedicated Slipring

Total 8 Article(s) 1 Page(s)
  • 8
    • zoom in

    • Optical Slip Ring SKS-OPT01-17

      Items Product Specifications

      Circuits

      		 1 Core

      Rotation Speed

      Max 500 rpm

      Using Wavelength

      650-1650 nm

      Cable Length

      STATOR 500mm / ROTOR 500mm

      Cable Tensile

      		 (10)N

      Cable Material

      2.9mm, 3mm의 Kevlar / PVC

      ※ Kevla made in USA (High strength fiber)

      Connector Type

      Standard SC Connetor

      ※  FC, FC / APC, or  ST avaiible

      Housing Material

      		 Stainless

      Torque

      		 < 0.1 Nm

      Optical Loss

      < 3 dB  (General : +/- 0.15 dB)

      Using Temerature

      		    -40 ° C ~ 85

      Communication cable Spec

      Various Communication Module available depends on converter specs

      ※ Inquiry for Communication spec available
  • 7
    • zoom in

    • Optical Slipring SKS-OPT01-10

      Items Product Specifications

      Circuits

      		 1 Core

      Rotation Speed

      Max 500 rpm

      Using Wavelength

      650-1650 nm

      Cable Length

      STATOR 500mm / ROTOR 500mm

      Cable Tensile

      		 (10)N

      Cable Material

      2.9mm, 3mm의 Kevlar / PVC

      ※ Kevla made in USA (High strength fiber)

      Connector Type

      Standard SC Connetor

      ※  FC, FC / APC, or  ST avaiible

      Housing Material

      		 Stainless

      Torque

      		 < 0.1 Nm

      Optical Loss

      < 3 dB  (General : +/- 0.15 dB)

      Using Temerature

      		    -40 ° C ~ 85

      Communication cable Spec

      Various Communication Module available depends on converter specs

      ※ Inquiry for Communication spec available
  • 6
    • zoom in

    • SKS-RF01-15 (Video / RF)

      Item Specification
      Electric Number of Circult 1 circuit
      Cable spec RG-179/U
      Operating Speed 50 rpm
      Impedance 75Ω

      Frequency range

      Max DC 2.3GHz

      Current Rating

      Max 1A

      Temperature range

      -40℃ ~ +80℃

      Noise

      Insertion loss : -0.65dB / 1GHz Max

      Return loss : -18dB / 1GHz Max

      Maker

      Taiwan
  • 5
    • zoom in

    • SKS-RF01-07 (VIDEO / RF)

      Item Specification
      Electric Number of Circult 1 circuit
      Cable spec RG-179/U
      Operating Speed 50 rpm
      Impedance 75Ω

      Frequency range

      Max DC 2.3GHz

      Current Rating

      Max 1A

      Temperature range

      -40℃ ~ +80℃

      Noise

      Insertion loss : -0.65dB / 1GHz Max

      Return loss : -18dB / 1GHz Max

      Maker

      Taiwan
  • 4
    • zoom in

    • SKS-ENCODER

      Item Specification
      Number of Circuit 5/7/9 circuit (1 circuit GND )
      Operating Speed 200 rpm
      Lead Lengths 500 mm
      Cable type UL2464 (24 AWG)
      Contact Material

      Silver or Gold
      Noise

      100 milliohm Max.Tested 6 VDC, 50 milliamps when running @ 5 rpm

      ※ 반드시 COOLER SYSTEM 장착
  • 3
    • zoom in

    • SKS-USB

      Item Specification
      Number of Circuit

      USB(ver 1.1 / 5 circuit (1 circuit GND )

      USB(ver 2.0 / 5 circuit (1 circuit GND )
      Operating Speed 200 rpm
      Lead Lengths Max 300 mm
      Cable type USB DEDICATED CABLE

      DATA Transfer rate

      USB ver 1.0, 1.1 : 10Mb / s

      USB ver 2.0 : 20Mb / s

      (전원용 USB 허브 또는 리피터 사용을 추천)
      Contact Material Silver or Gold
      Lead Size/Type Silver Plated copper Type
      Teflon insulated
      Noise 100 milliohm Max.Tested 6 VDC, 50 milliamps when running @ 5 rpm
  • 2
    • zoom in

    • SKS-RS

      Item Specification
      Number of Circuit

      RS 232 / 3 circuit (1 circuit GND )

      RS 422, 485 / 3 , 5 circuit (1 circuit GND )
      Operating Speed 200 rpm
      Lead Lengths 500 mm
      Cable type UL2464 (24 AWG) Pair CABLE
      Contact Material

      Silver or Gold
      Lead Size/Type Silver Plated copper Type
      Teflon insulated
      Noise 100 milliohm Max.Tested 6 VDC, 50 milliamps when running @ 5 rpm
  • 1
    • zoom in

    • SKS-ETHERNET

      Item Specification
      Number of Circuit 5/9 circuit (1 circuit GND )
      Operating Speed 200 rpm
      Lead Lengths 500 mm
      Cable type UL2464 (24 AWG) Pair UTP CABLE (CAT 5e)
      DATA Transfer rate

      10 / 100 Mbps

      (DATA의 손실이 발생할 경우 허브를 권장)
      Contact Material Silver or Gold
      Lead Size/Type Silver Plated copper Type
      Teflon insulated
      Noise 100 milliohm Max.Tested 6 VDC, 50 milliamps when running @ 5 rpm
